Discovery of New Method Speeds Up Precision 3D BioprintingAndrew Wheeler posted on November 19, 2019 |

In the world of additive manufacturing (AM), the promises of bioprinting would be truly groundbreaking if they were to be kept and fully realized. The unscalable mountain is the ability to 3D print patient-specific organs. There would be no more organ rejection from transplants in post-operative care. In 2017, Gartner predicted that this medical innovation would occur within a decade.

Currently, simple tissues are 3D printed by various companies. For example, Poietis established and commercialized a laser methodology for 3D printing biological matter like skin cells and liver tissue. They released a commercial skin product in 2018 and established a partnership with LOral and BASF. Another example comes from the company CELLINK. It makes bioprinters used by pharmaceutical researchers in order to test the effects of drugs on living human tissue.

The technology and techniques of 3D bioprinting still have a long way to go before patient-specific organ transplants transform from fantasy to reality. Recent developments from TU Wien in Austria highlight one of the main factors in achieving what is now impossible: speed.

These are living cells photographed in a 3D scaffold. Weeks 1, 3 and 5 are pictured from left to right. The top images show the 3D setup and the bottom shows just one layer. The indications for increased precision and speed are significant for bioprinting and the ultimate goal of 3D printing patient-specific organs for transplants. (Image courtesy of TU Wien.)

The 3D scaffold and bioink developed at TU Wien will allow researchers to achieve new levels of accuracy in ongoing studies about the behavior of cells. The cell behavior as diseases spread is an important aspect of discovering new treatment methods. The introduction of stem cells to the new process makes it possible to create fully customized tissue.

3D bioprinting techniques differ in many ways. Some are less precise while others produce cells that do not last very long. Some cells produced through 3D bioprinting have material properties that limit their efficacy.

Cell behavior can differ greatly depending the chemical properties, shape and mechanical nature of the environment. For example, it is important for the environment to be permeable in order to ensure the survival and multiplication of cells embedded within. Countering that, the environment must strike the right type of balance in respect to stiffness and flexibility so that the structures do not degrade.

The key is to have new environments for embedding the cells, either liquids or gels, that solidify exactly where they are shot with a focused laser beam. The catch-22 is that the laser beam and the materials must not in any way harm the embedded living cells, and it has to happen as rapidly as possible.

TU Wien researchers solved this complex issue by using two-photon polymerization methods. These methods use a chemical reaction that has specific prerequisites for activation. When a molecule of the material that makes up the environment where the living cells are embedded absorbs two photons, an extremely intense laser beam activates a chemical reaction. At the precise point where the two photons are absorbed, the environmental substance stiffens but the surroundings remain liquid. The level of precision and intricacy at which structures can be constructed increases.

This process alone is slow, but using scaffolds has helped researchers develop a method that enables them to print structures in a few hours. Additionally, these new structures have an increased likelihood of surviving and living longer.

Researchers can now define exactly how an environmental structure should behave to foster specific types of cell migration and growth. They also can predict with greater accuracy how long a structure will last and when it will degrade.
